Gea Niro Soavi NS3037/30P
High pressure homogeniser. 2 Stages with pneumatic pressure control. 3 Ceramic pistons, piston diameter: 50 mm and stroke: 70 mm. With ball valves 1" 1/4 (PVB). Stainless steel cladded with sound reducing insulation. Connections in: 2,5" Din and outlet: Flange 1". Current motor power: 30 kW - 56A - 50 Hz and maximum pressure in current confirguration with this motor 250 bar. Overpressure valve set on 300 bar. 3x Manometer (pressure) on head with. 3x electronic pressure transmitters. Pulsation demper on inlet. With tools and spare parts. Currently no controls, can be offered upon request. Documentation available: Instruction manual with PID, technical drawings and parts list available (multiple languages).
